KV-168C/C-0 雙溫控氣動罩杯定型機
KV-168C/C-0 Bra cup molding machine
用途：主要用于內衣模杯產品及其它同類產品的定型生產。
特點：結構簡單，使用方便�？煞譃槎䴗乜睾退臏乜�。物美價廉，生產效率高，成本低。
技術參數：
電源/功率：220V/4KW
電熱片規格：Φ12×180mm×500W-220V
模臺尺寸：360mm×175mm
機臺尺寸：800mm×600mm×1700mm
適用物料：文胸的熱壓定型
適用模具：文胸棉模模具
重量：100KG
Function: It is suitable for producing molded bra cups and other similar products.
Features: The structure is simple and it is easy to operate. There are divided into two temp controls and four temp controls. Excellent in quality and reasonable in price, it has high production efficiency but low cost.
Technical parameter:
(1) Power supply/power: 220 V/4KW
(2) Specification of the electrothermal piece: Φ12×180mm×500W-200V
(3) Dimension of the mould table: 360mm×175mm
(4) Dimension of the machine: 800mm×600mm×1700mm
(5) Applicable material: the thermo-compression of bra
(6) Applicable moulds: moulds for foam bra cup
(7) Weight: 100KG
